Raytek RAYST61 ST Pro Plus Infrared Thermometer with 30:1 Optics, -32 to 600°C (-25 to 1100°F)

Model: RAYST61

Raytek RAYST61 ST Pro Plus Infrared Thermometer with 30:1 Optics, -32 to 600°C (-25 to 1100°F)-


Downloads: datasheet manual

Raytek RAYST61 ST Pro Plus Infrared Thermometer with 30:1 Optics, -32 to 600°C (-25 to 1100°F)

Model: RAYST61

Compact, rugged, and easy-to-use infrared with laser sighting for fast, accurate non-contact temperature measurements, also performs contact measurements with the included Type K thermocouple wire probe.

Compact, rugged, and easy-to-use infrared with laser sighting for fast, accurate non-contact temperature measurements, also performs contact measurements with the included Type K thermocouple wire probe.

Sale Price $401.86 USD
Regular Price $449.00 USD
Availability 5 in Stock
Quantity

Add In-House Traceable Calibration to your RAYST61

Add In-House Traceable Calibration to your RAYST61


Raytek RAYST61 Offers

Features

  • Quickly, accurately and safely measure surface temperatures of hot, hazardous, moving, or hard-to-reach objects without contact
  • Simple to use, just point and pull the trigger
  • Laser guided sighting system for easy targeting with 1% accuracy
  • Advanced optics to measure smaller targets at greater distances
  • Adjustable emissivity for more accurate temperature measurements
  • Built-in table of emissivity values for most common materials
  • Selectable MAX, MIN, DIFF and AVG functions that display values instantly with Hi/Lo Alarm
  • Display Hold and backlight with two brightness levels
  • Expanded measurement range up to 1100°F (600°C)
  • Data logging up to 20 records, including time, date, emissivity and temperature data
  • Included probe accessory for dual contact and non-contact temperature measurements

Raytek RAYST61 Specifications

Temperature Range -32 to 600°C (-25 to 1100°F)
Resolution 0.1ºC (0.1ºF)
Accuracy <0°C (32°F): ±[1°C (2°F) + 0.1°/1°C (°F)]; ≥0°C (32°F): ±1% of reading or ±1°C (±2°F), whichever is greater
Repeatability ±0.5% or ≤ ±1ºC (±2ºF), whichever is greater
Emissivity Digitally adjustable from 0.10 to 1.00 by 0.01
Optical Resolution 30:1 (Distance to Spot Size)
Spectral Response 8-14µm
Response Time ≤ 500ms (95% of reading)
Type K T/C Input Temperature Range -270 to 1372°C (-454 to 2501°F)
Resolution 0.1ºC (0.1ºF)
Accuracy -270 to -40°C (-454 to -40°F): ±[1°C (2°F) + 0.2°/1°C (°F)]; -40 to 1372°C (-40 to 2501°F): ±1% of reading or ±1°C (±2°F), whichever is greater
Type K Wire Probe Temperature Range -40 to 260°C (-40 to 500°F)
Accuracy ±1.1°C (±2.0°F)
Click here for complete specifications on the Raytek RAYST61

What's included with the Raytek RAYST61

  • Infrared thermometer
  • Type K thermocouple wire bead probe, 1m (40")
  • Two AA batteries
  • Hard case

Customer Reviews for the Raytek RAYST61

Ask a question about Raytek RAYST61 ST Pro Plus Infrared Thermometer with 30:1 Optics, -32 to 600°C (-25 to 1100°F)

Raytek RAYST61 Offers

Features

  • Quickly, accurately and safely measure surface temperatures of hot, hazardous, moving, or hard-to-reach objects without contact
  • Simple to use, just point and pull the trigger
  • Laser guided sighting system for easy targeting with 1% accuracy
  • Advanced optics to measure smaller targets at greater distances
  • Adjustable emissivity for more accurate temperature measurements
  • Built-in table of emissivity values for most common materials
  • Selectable MAX, MIN, DIFF and AVG functions that display values instantly with Hi/Lo Alarm
  • Display Hold and backlight with two brightness levels
  • Expanded measurement range up to 1100°F (600°C)
  • Data logging up to 20 records, including time, date, emissivity and temperature data
  • Included probe accessory for dual contact and non-contact temperature measurements

Raytek RAYST61 Specifications

Temperature Range -32 to 600°C (-25 to 1100°F)
Resolution 0.1ºC (0.1ºF)
Accuracy <0°C (32°F): ±[1°C (2°F) + 0.1°/1°C (°F)]; ≥0°C (32°F): ±1% of reading or ±1°C (±2°F), whichever is greater
Repeatability ±0.5% or ≤ ±1ºC (±2ºF), whichever is greater
Emissivity Digitally adjustable from 0.10 to 1.00 by 0.01
Optical Resolution 30:1 (Distance to Spot Size)
Spectral Response 8-14µm
Response Time ≤ 500ms (95% of reading)
Type K T/C Input Temperature Range -270 to 1372°C (-454 to 2501°F)
Resolution 0.1ºC (0.1ºF)
Accuracy -270 to -40°C (-454 to -40°F): ±[1°C (2°F) + 0.2°/1°C (°F)]; -40 to 1372°C (-40 to 2501°F): ±1% of reading or ±1°C (±2°F), whichever is greater
Type K Wire Probe Temperature Range -40 to 260°C (-40 to 500°F)
Accuracy ±1.1°C (±2.0°F)
Click here for complete specifications on the Raytek RAYST61

What's included with the Raytek RAYST61

  • Infrared thermometer
  • Type K thermocouple wire bead probe, 1m (40")
  • Two AA batteries
  • Hard case
